The goal for this tweeter series was to create a transducer that has a frequency response that is flat to above 20K, and where the distortion is far lower than normal and more friendly to the ear. The tweeters represent a unique approach to tweeter design that has resulted in unrivaled performance, as well as in several patents (Dual Ring Radiator diaphragm, wave-guide center plug).

FEATURES

• Dome tweeter
• High performance
• Coated silk dome tweeter
• Ferro fluid cooling
• Linear response faceplate
• Braided tinsel leads
• Double chamber for lower resonance.
• High frequency extension to 30 KHz.

SPECS

• D27TG35-06
• Type Tweeter
• Sensitivity 91.8 dB
• Fs 900 Hz
• Qts 0.54
• Impedance 6 Ω
• Size 25 mm
• Power 100 W
